920mm Infrared Drying Machine Stainless Steel Transmission System

Large Image : 920mm Infrared Drying Machine Stainless Steel Transmission System

Product Details:

Place of Origin:	CHINA
Brand Name:	Osmanuv
Certification:	ISO9001
Model Number:	OSM-IR-920

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Negotiable
Packaging Details:	Wooden box
Delivery Time:	30 WORK DAYS
Payment Terms:	T/T,Western Union

Contact Now

920mm Infrared Drying Machine Stainless Steel Transmission System

Description

Product Name:	Infrared Drying Machine	Warranty:	1 Year
Specification:	9000mm Long X 1250mm Wide X 1400mm High	Color:	Computer White / Green
Effective Leveling Width:	920mm	Model No.:	OSM-IR-920
Highlight:	mechanical Infrared Drying Machine , 920mm Stainless Steel Transmission System , 920mm Infrared Drying Machine

920mm Infrared Drying Machine Stainless Steel Transmission System

Product Overview

A dryer is mechanical equipment that utilizes heat energy to reduce material moisture content, effectively drying various objects. Through controlled heating, this system vaporizes and removes moisture (or other volatile liquid components) from materials, producing solid materials with precisely specified moisture levels.

Technical Specifications

1	Specifications:	9000mm long x 1250mm wide x 1400mm high
2	Material:	The shell of the heating area is made of A3 board, with insulation cotton in the middle
3	Lamp tube:	Using Taiwan quartz heating tube, providing excellent heating effect
4	Effective leveling width:	920mm
5	Conveyor belt:	Stainless steel chain rod type
6	Transmission system:	The transmission motor adopts Taiwan TWT gear reducer
7	Control system:	Using Taiwan Delta frequency converter, speed adjustable 5-20m minutes, with speed digital display
8	Control system:	BKC temperature controller controls required temperature, adjustable from room temperature to 100℃

Product Image
