Square Bucket Spin Coating Machine with Customizable Fixture High Transfer Efficiency and Multi-Station Operation

Square Bucket Spin Coating Machine with Customizable Fixture High Transfer Efficiency and Multi-Station Operation
Square Bucket Spin Coating Machine with Customizable Fixture High Transfer Efficiency and Multi-Station Operation Product Overview This spin coating system is specifically engineered for applying uniform, high-performance functional coatings (water-resistant, oil-resistant, barrier coatings) to the ...
Place of Origin:CHINA
Brand Name:OSMANUV
Certification:ISO9001
Model Number:Specification
Minimum Order Quantity:1 Set
Price:Negotiation
Product Custom Attributes
Highlight

Customizable Fixture Spin Coating Machine

,

High Transfer Efficiency Pulp Molding Coating Machine

,

Multi-Station Operation Square Bucket Coating System

Voltage:
220V,380V,380V/220V,220V/380V,380V/50HZ
Condition:
New
After-sales Service Provided:
Engineers Available To Service Machinery Overseas,Video Technical Support,Online Support,Overseas Third-party Support Available,Field Installation
Type:
Coating Machine,Coating Production Line,Printing Paper UV Varnish Coating Machine,Other,1320mm
Automatic Grade:
Automatic,Semi-Automatic,manual,Other
Packaging Material:
Wood
Packaging Type:
Case,Cartons,Film,Wooder Package,Bags
Warranty:
1 Year
Product Description
Square Bucket Spin Coating Machine with Customizable Fixture High Transfer Efficiency and Multi-Station Operation

Product Overview
This spin coating system is specifically engineered for applying uniform, high-performance functional coatings (water-resistant, oil-resistant, barrier coatings) to the internal surfaces of square bucket molded pulp products. Using centrifugal force technology and precision dispensing, it ensures seamless, pinhole-free film coverage even on complex 3D interior geometries including deep corners and sidewalls.
Working Principle
Square buckets are securely held on custom fixtures on the rotary indexing table. At each spin station, precision dosing pumps dispense coating material onto the product interior, followed by high-speed spinning that evenly spreads the coating across complex interior geometries. Coated products then pass through multi-stage drying tunnels to achieve a uniform barrier film with minimal material waste (>90% transfer efficiency).
The system is available in customizable configurations ranging from single-station R&D units to fully automated high-speed production lines. Available in rotary indexing, modular robotic, and integrated drying configurations.
Technical Specifications
Parameter Specification / Range Customization Options
Model Series OSM-XT Series Custom model designation available
Number of Work Stations 1, 4, 6, 12, or 24 positions Customizable station count
Production Capacity 5-35 cycles/min (360-1,200 pcs/hr) Customizable speed profiles
Applicable Bucket Size (L×W×H) Up to 400×300×150mm (standard) Customizable fixture dimensions
Spin Speed Range 100 - 8,000 RPM (programmable) Customizable max speed up to 15,000 RPM
Coating Thickness 5-25 gsm (dry) / 10-100 μm Customizable thickness via volume + speed
Coating Uniformity >95% thickness consistency Optimized via multi-zone customization
Coating Method Precision metering pump + spin Customizable pump type per viscosity
Coating Transfer Efficiency >90% (closed-loop system) --
Drying/Curing Method IR pre-dry + hot air tunnel / UV curing Customizable drying technology
Temperature Range Ambient - 150°C (adjustable) Customizable per coating type
Control System PLC with 7-10" HMI touchscreen Customizable protocols (PROFIBUS, Ethernet, IoT)
Recipe Storage 100+ product recipes Customizable recipe library
Power Supply 380V / 50Hz / 3-Phase (standard) Customizable to 220V / 60Hz
Total Power Consumption 5-120 kW (configuration-dependent) Depends on station count + drying load
Compressed Air 0.6-0.8 MPa, clean & dry --
Machine Weight 110 - 3,000 kg (varies by model) Configuration-dependent
Safety Standards CE, ISO9001 compliant Additional certifications available
Main Construction Material 304 Stainless Steel (frame), food-grade fluid paths Customizable material upgrades
Applications
  • Food Packaging: Square molded pulp buckets, containers, and food trays requiring waterproof/oil-proof PFAS-free barrier coatings
  • Disposable Tableware: Pulp-molded square bowls, soup containers, lunch boxes with internal coating
  • Agricultural Containers: Coated square pots and horticultural containers
  • Industrial Packaging: Square molded pulp packaging requiring barrier protection
  • Premium Packaging: High-end retail packaging needing superior surface finish and protection
  • Material Compatibility: Compatible with aqueous dispersions (PE, PLA, bio-based barriers), PFAS-free solutions, and various coating viscosities
Key Features
  • Precision Coating: Individual servo-controlled dosing and spinning guarantee consistent coating weight and thickness on square bucket interiors
  • Uniform Coverage: Centrifugal force ensures seamless, pinhole-free coverage even on deep corners and sidewalls
  • High Transfer Efficiency: >90% material utilization, minimizing waste and reducing VOC emissions
  • High Efficiency: Multi-station continuous operation with production capacity up to 1,200 pcs/hr
  • Smart Control: PLC system with HMI touchscreen for recipe management and real-time monitoring
  • Quick Changeover: Modular tooling design allows for fast product changeover between different bucket sizes
  • Rapid Drying Cycle: Integrated multi-stage drying tunnel speeds up production
  • Robust & Hygienic: 304 Stainless Steel construction, easy to clean and maintain
  • Energy Saving: 30% less energy consumption than conventional methods
  • Data Logging: Full process parameter recording for quality traceability and compliance
Customization Options
Customization Area Options
Station Count & Layout Customizable from 1 to 24+ stations to match production capacity
Fixture / Chuck Design Custom-machined fixtures for specific square bucket geometries (vacuum, mechanical clamp, custom nests)
Spin Speed & Acceleration Customizable speed profiles for different coating materials
Dispense System Customizable pump type and capacity for different coating viscosities
Drying Method Customizable -- IR, hot air, UV-LED, NIR, or combination
Drying Tunnel Length Customizable based on coating curing profile
Temperature Range Customizable up to 200°C for specific coatings
Control System Customizable automation protocols and data logging features
Voltage/Frequency Customizable to local electrical standards
Integration Customizable I/O interfaces for seamless integration with existing lines
Automation Level Semi-automatic to fully automatic (customizable)
Brand Options Electrical/pneumatic component brands per client request
Support & Services
Service Description
Project Consulting Feasibility analysis and process solution design
Sample Testing Free sample testing and process development
Installation & Commissioning On-site setup guidance and operator training by experienced engineers
Warranty 12 months standard warranty (customizable extension available)
Remote Support 24/7 remote troubleshooting and maintenance support
Spare Parts Fast delivery of genuine spare parts (nozzles, pumps, belts, etc.)
Software Updates Regular software upgrades and technical improvements
Operator Training Comprehensive training on proper usage and safety
Custom Design Co-engineering service for fully customized coating solutions
Packing & Shipping
Item Details
Packaging Heavy-duty export wooden box with waterproof protection
Internal Protection Components securely fastened; sensitive electronics shock-mounted
Documentation Complete shipping documents (packing list, invoice, etc.)
Delivery Terms FOB / CIF / Door-to-door logistics (customizable)
Standard Delivery Time 30 - 45 working days
Customized Delivery Time 40 - 60 days after final specification confirmation
Frequently Asked Questions
Q: What types of square buckets can this machine handle?
A: The system handles various square/rectangular molded pulp buckets and containers. Fixtures are customizable to match your specific bucket geometry, including size, depth, and corner radius.
Q: Can the line handle different bucket shapes in the same batch?
A: For optimal efficiency, it is designed for running batches of the same product. Quick-change customizable fixture systems are available to reduce changeover time between different products.
Q: What is the typical coating thickness range?
A: Typical dry coating weight is 5-25 gsm, with thickness accuracy within ±1%. Coating thickness can be customized by adjusting dispensed volume and spin speed parameters.
Q: How is coating thickness controlled?
A: Thickness is controlled by the precise combination of dispensed volume, spin speed, and spin time. These parameters are digitally set and repeatable within each recipe on the PLC system.
