Energy-Efficient Cold Cure UV-LED Curing System with Customizable Wavelength for Pulp Molding
Energy-Efficient UV-LED Curing System
,Cold Cure UV Curing Machine
,Customizable Wavelength LED-UV Curing Equipment
This UV curing system utilizes the latest LED technology to provide an energy-efficient and environmentally friendly curing solution for pulp molded products. It emits a precise wavelength of UV light, resulting in minimal heat generation ("cold cure"), drastically lower energy consumption, and zero ozone production. The system is ideal for heat-sensitive pulp substrates and sustainable manufacturing initiatives.
For coating applications, the high-speed spin coating line applies uniform waterproof, oilproof, and anti-mold internal coatings using centrifugal force technology, ensuring precise thickness control for food packaging and liquid containers requiring exceptional leakage protection. For decorative applications, the digital printing system enables direct, high-resolution printing on flat, curved, or 3D irregular pulp surfaces—eliminating plate costs and making short runs economically feasible.
| Parameter Category | Specification | Notes / Customization Options |
|---|---|---|
| UV Source | LED Array | Customizable wavelength: 365nm, 385nm, 395nm, 405nm |
| Peak Irradiance | Up to 20 W/cm² | High intensity for fast curing |
| Lamp Life | > 20,000 hours | Massive reduction in maintenance and consumable costs |
| Power Consumption | ~70% less than arc lamp | Drastically lowers operational costs (OPEX) |
| Curing Temperature | < 40°C (104°F) | "Cold Cure" prevents warping of delicate pulp products |
| Instant On/Off | Yes | No warm-up or cool-down, saves energy |
| Control System | PLC with Ethernet/IP | Energy monitoring dashboard; customizable interface language |
| Production Speed | 40-80 pcs/min (coating line); up to 60 m/min (printing) | Adjustable based on product size and resolution |
| Coating Thickness | 10-100 μm | Precision control ±2 μm; customizable per product |
| Print Resolution | 600 × 600 dpi (standard) | Customizable up to 1200 × 1200 dpi; user-selectable modes |
| Printable Geometry | 3D & irregular surfaces | Supports flat, curved, convex, and recessed surfaces |
| Array Size / Width | Customized per project | Fully customizable from 200 mm to 1,800 mm+ |
| Power Supply | 380V/50Hz/3Phase (standard) | Customizable to local voltage/frequency |
| Machine Dimensions | Project-dependent | Customizable layout to fit your production floor |
- Food Service Packaging: High-speed coating/printing on plates, bowls, clamshell containers, trays, and cups—with waterproof, oilproof barrier properties
- Fruit & Egg Trays: Branding, PLU codes, or origin labeling on textured agricultural transport trays
- Premium Consumer Packaging: Exquisite inner liners and outer packaging for electronics, cosmetics, jewelry, and gifts
- Industrial Protective Packaging: Corner protectors, cushioning inserts with traceability codes
- Medical & Cosmetic Packaging: High-resolution branding and lot/batch coding
- Agricultural Pots: Planting instructions, date coding, or brand identity on biodegradable horticultural pots
- Wavelength Selection: Customizable LED wavelength (365nm, 385nm, 395nm, 405nm) to match your specific photoinitiator package
- Array Size & Shape: Scalable to your product's geometry, line speed, and curing width requirements
- Coating Thickness & Layers: Tailored thickness for specific waterproof/oilproof requirements; additional coating layers for enhanced barrier properties
- Print Resolution & Color Configuration: Customizable from 2 to 8 colors + optional spot colors; resolution modes user-selectable per job
- Product Geometry Support: Up to 5-sided continuous printing for irregular 3D surfaces
- Integration Services: Retrofit to existing production lines or turnkey new installations
- Automation Level: Semi-automatic, fully automatic, or high-efficiency customized systems
- Mold Development: Custom molds based on product drawings, samples, or packaging requirements
- Multi-Language Interface & control systems
| Service | Description |
|---|---|
| Sample Testing | Sample testing and process development |
| Installation & Training | On-site installation guidance and operator training by experienced engineers |
| Warranty | 12-month warranty on main components |
| Remote Support | Lifetime remote troubleshooting and maintenance support |
| Software Updates | Regular software updates and technical improvements |
| Turnkey Project | Complete line design, equipment selection, mold development, and training support |
| Energy Reports | Detailed energy saving reports and TCO analysis |
- Packaging: Heavy-duty export packaging with waterproof protection; LED-UV modules are shock-mounted and shipped in custom foam-insulated crates to protect sensitive optics
- Custom Crating: Customized crating for sensitive components
- Documentation: Complete shipping documentation handled professionally
- Delivery: Worldwide delivery with tracking information; on-time delivery guarantee
- Lead Time: Typically 45 days for standard systems; 10-12 weeks for custom configurations after final design confirmation
-
