Product Details:

Place of Origin: China
Brand Name: Osmanuv
Certification: ISO9001
Model Number: OSM-UV-102TP

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Wooden box
Delivery Time: 20 work days
Payment Terms: Western Union, T/T
Get Best Price Contact Now

Detail Information

Color: Computer White / Black Product Name: Uv Curing System
Working Speed: 1-13 M/min Working Width: 300mm×350mm
Total Power: 2.15KW Dimensions: L:1220mm W:470mm H:460mm
High Light:

2.15KW uv curing conveyor systems

,

13m/Min uv curing conveyor systems

,

2.15KW uv led curing equipment

Product Description

2.15KW 13m/Min Instant Black Led Uv Curing Conveyor Systems



Description:

1

High efficiency UV beam can make UV paint, glue, ink and so on fast and instant curing (time 5-8 seconds).


 2

Application:


It is used for quick UV curing of all kinds of plastic parts by spraying UV paint, coating, varnish and so on
 3 Power supply: 220VAC/50HZ. Total power: 2.15KW.
 4 Specifications: 1220mm long × 470mm wide × 460mm high.
 5

UV lamp:


2 1KW UV lamp tubes are used, installed on the top of the UV furnace, illuminating downward, and the height and angle are adjustable.
 6 UV lampshade: The unique aluminum reflective material (German alanod reflector) is used to reflect ultraviolet light, which is durable and greatly improves the utilization rate of ultraviolet light (more than 38%).
 7 Width of conveyor network:

300mm. Height of inlet and outlet: 130mm.


 8 Lampshade: Adjustable height is 80mm.
 9 Transmission speed: 1~10m/min, stepless speed regulation.
 10

Conveyor belt:


mesh belt is used as transmission power, high temperature resistance, UV resistance and stable conveying.
  11 Housing material: 1.5 cold-rolled plates are bent and welded, and the housing is spray-baked, wear-resistant and corrosion-resistant.
 12 Cooling system: forced air cooling.
 13 Electrical part:

CKC time delay, OMRON relay, famous switch, CHNT contactor, leakage circuit breaker and other famous-brand electrical appliances that comply with international safety standards.


 14 Control panel:

UV lamp ammeter, power indicator, power switch, UV lamp switch, time accumulator.


 15

Safety devices:


leakage circuit breakers, control circuit fuses, etc., in line with international safety standards.
17

Warranty:

One year for the whole machine, half a year for the electrical part, and 800-1000 hours of UV lamp warranty.





FAQ


Q: Are you trading company or manufacturer?
A: We are a manufacturer owns foreign trade independent import and export rights. Our factory is located in Guangdong, China.
Q: How can I know your machine has good quality?
A: Firstly, we will have your samples for a trial on our machines, and make a video for you to watch the testing, factory visit is also available. Moreover, our products are widely used in China, Southeast Asia, South America, and Europe.
Q: What certifications do you have?
A: Fully in accordance with the GMP & ISO standard production and our products have passed CE certification for exporting.
Q: What is your Quality Warranty?
A: One year warranty; Lifelong Maintenance and Technical Support.
