High Speed Food Grade UV Sterilization Machine for 99.9% Pathogen Elimination

High Speed Food Grade UV Sterilization Machine for 99.9% Pathogen Elimination
High Speed Food Grade UV Sterilization Machine for 99.9% Pathogen Elimination High Speed Food Grade UV Sterilization Machine for 99.9% Pathogen Elimination High Speed Food Grade UV Sterilization Machine for 99.9% Pathogen Elimination High Speed Food Grade UV Sterilization Machine for 99.9% Pathogen Elimination

Large Image :  High Speed Food Grade UV Sterilization Machine for 99.9% Pathogen Elimination

Product Details:
Place of Origin: CHINA
Brand Name: OSMANUV
Certification: ISO9001
Model Number: OSM-UVC40-500AL
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: WOOD PACKAGING
Delivery Time: 30 days
Payment Terms: T/T
Supply Ability: Negotiation
Contact Now

High Speed Food Grade UV Sterilization Machine for 99.9% Pathogen Elimination

Description
Dimension(l*w*h): Customized Size，3000mm * 700mm * 1350mm Effective Width: 500mm
Voltage: 380V/60HZ Coating Speed: Adjustable,1-10m/min,can Be Set By Yourself
Material: SUS 304 Stainless Steel After-sales Service Provided: Video Technical Support
Condition: New Warranty: 1 Year
Highlight:

UV sterilization machine food grade

,

high speed UV pathogen eliminator

,

UV curing machine with warranty

High Speed Food Grade UV Sterilization Machine for 99.9% Pathogen Elimination
This food-grade UV sterilization machine is engineered for high-speed, non-thermal sterilization of food products and packaging. Utilizing 40 powerful 30W UVC lamps arranged above and below the conveyor, it ensures thorough 360-degree exposure, effectively eliminating up to 99.9% of bacteria, viruses, and molds without chemicals or heat, preserving product quality and extending shelf life.
Technical Parameters
No. Parameter Name Specification
1 Model OSM-UVC40-500AL
2 Machine Dimensions (L×W×H) 3000mm × 700mm × 1350mm
3 Effective UV Sterilization Zone 2000mm
4 Conveyor Belt Food-Grade Teflon Mesh Belt
5 Conveyor Speed 1-10 m/min, Stepless Speed Regulation
6 UVC Lamps 40 x 30W Germicidal Lamps
7 Material Full SUS 304 Stainless Steel
8 Power Supply 380V, 60Hz
9 Control System PLC Control Panel with Timer
Application
Ideal for surface sterilization of ready-to-eat foods, fruits, vegetables, baked goods, meat packaging trays, and food containers.
Customization
We offer customizable conveyor speeds, tunnel lengths, and UV intensity settings to achieve the specific Log reduction required for your products.
Features
  • Dual-sided UV irradiation for maximum microbial kill rate
  • Constructed with full SUS 304 stainless steel for hygiene and durability
  • PLC-controlled for precise operation and repeatable results
  • Non-thermal process preserves food flavor, texture, and nutritional value
Support and Services
  • One-year full machine warranty, half-year for electrical components
  • Lifetime technical support and remote troubleshooting
  • Guidance on lamp replacement and preventive maintenance
Packing and Shipping
The machine is securely packed in a wooden crate for safe transport. It is available as stock, with shipment within 3 working days after full payment.
Frequently Asked Questions
Q: What is the efficiency of this machine against E. coli and Salmonella?
A: The system is designed to achieve a 99.9% (3-log) reduction or higher on such pathogens with appropriate exposure time (conveyor speed).
Q: Can the machine be integrated into our existing production line?
A: Yes, the height and conveyor speed are customizable for seamless integration.
