Product Details:

Place of Origin: China
Brand Name: Osmanuv
Certification: ISO9001
Model Number: OSM-UV-202TZ

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Wooden box
Delivery Time: 30 work days
Payment Terms: T/T, Western Union
Get Best Price Contact Now

Detail Information

Product Name: Uv Curing System Warranty: 1 Year
Total Power: 4.8W Feeding Speed: 1-8 M/min
Color: Computer White Working Width: 200mm
Machine Weight: 100kg

Product Description

omron relay Uv Curing Machinete flon conveyor belt LCD LED Glue Quickiy UV Curing Machine



Description:



Technical parameters and characteristics:

 1  Product name UV light curing machine.
 2 Model: GX-UV-202A desktop light curing machine.
 3 Power supply: 220V/50HZ
 4 Specifications: 1250mm long × 550mm wide × 490mm high.
 5 Material: The shell is made by bending and welding 1.5mm cold-rolled plates, and the shell is painted, wear-resistant and corrosion-resistant, and the color is computer white.
 6 UV lamp: Two 2 KW UV lamps are used, which are installed on the top of the UV furnace to illuminate downwards. The height and angle of the UV lamp are fixed.
 7 Effective irradiation: 350mmX 400mm,
 8 Conveyor belt: conveyor belt is adopted, which is resistant to ultraviolet rays and easy to clean.
 9 Speed ​​control system:

A speed-adjusting motor is equipped with a gear box as the transmission power, the speed is adjustable from 0-10 m/min, and the panel is controlled.


 10 UV lampshade: using professional reflective material (German alanod reflector) to reflect ultraviolet light, internally equipped with quartz lenses, which can effectively filter infrared rays and transmit ultraviolet light, greatly improving the utilization rate of ultraviolet light (more than 38%).
 11 Cooling system: Using forced air cooling.
 12 Control system: Each lamp has an independent control system, and has a strong and weak light conversion, the light intensity is 75%, 100% adjustable.
 13 Electrical part: OMRON relay, CHNT contactor, CKC brand for delay time, and Japanese Izumi company production for switch.
 14 Safety devices: Leakage circuit breakers, over-temperature prevention, transformer motor overload protection, control circuit fuses... all comply with international safety standards.



FAQ


Q: Are you trading company or manufacturer?
A: We are a manufacturer owns foreign trade independent import and export rights. Our factory is located in Guangdong, China.
Q: How can I know your machine has good quality?
A: Firstly, we will have your samples for a trial on our machines, and make a video for you to watch the testing, factory visit is also available. Moreover, our products are widely used in China, Southeast Asia, South America, and Europe.
Q: What certifications do you have?
A: Fully in accordance with the GMP & ISO standard production and our products have passed CE certification for exporting.
Q: What is your Quality Warranty?
A: One year warranty; Lifelong Maintenance and Technical Support.
