ISO9001 Led Uv Dryer Machine With SUS304 Stainless Steel Conveyor

ISO9001 Led Uv Dryer Machine With SUS304 Stainless Steel Conveyor

Product Details:

Place of Origin: China
Brand Name: Osmanuv
Certification: ISO9001
Model Number: OSM-UV-302TZ

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Wooden box
Delivery Time: 30 work days
Payment Terms: T/T, Western Union
Get Best Price Contact Now

Detail Information

Product Name: Uv Curing System Dimension(l*w*h): L:2200 Mm X W:550 Mm X H:1700 Mm
Automatic Grade: Negotiable Warranty: 1 Year
Color: Computer White Weight: 335KG
High Light:

ISO9001 uv dryer machine

,

SUS304 uv dryer machine

Product Description

ISO9001 Led Uv Dryer Machine With SUS304 Stainless Steel Conveyor



Description:


■ UV light curing machine

 1 Product name: UV curing machine
 2 Model: OSM-UV-302TZ
 3 Specifications: 2100mm length × 290mm width × 1280mm height
 4 UV lamp:

use British PRIMARC lamp tube 2kw 2 as soon as possible,

(one facing down, one facing up).

 5 Conveying net width: 160mm (inlet and outlet opening 20mm-200mm)
 6   The height of the conveying net is 800-900mm.
 7 Effective irradiation width:
150mm.
 8 Conveyor belt: SUS304 stainless steel conveyor mesh belt is used for transmission.
 9 Housing material: 2mm cold-rolled plate is bent and welded, and the housing is painted in computer color.
 10 Speed ​​control system:

Adopt Taiwan Wanxin motor, reducer box as transmission power, speed adjustable 1-5 meters/minute, stepless speed regulation.

The panel control is equipped with a UV speed display.

 11 UV lampshade: Using professional reflective material (German alanod reflector) to reflect the ultraviolet light, durable and greatly improve the utilization rate of ultraviolet light (more than 30%).
 12 Cooling system: Use Kyushu HP fan, (one intake and one exhaust) heat dissipation effect is good. The air volume is adjustable.
 13

Electrical part:

Chint contactor is used, CKC brand is used for delay, and frequency conversion speed regulation system. The switch is produced by Japan's Izumi company, and the temperature control and relay are of OMRON brand.
 14 Control panel: UV lamp ammeter, power indicator, start switch, stop switch, fan working indicator, UV lamp switch, time accumulator (with reset function), emergency stop device on the machine.









FAQ


Q: Are you trading company or manufacturer?
A: We are a manufacturer owns foreign trade independent import and export rights. Our factory is located in Guangdong, China.
Q: How can I know your machine has good quality?
A: Firstly, we will have your samples for a trial on our machines, and make a video for you to watch the testing, factory visit is also available. Moreover, our products are widely used in China, Southeast Asia, South America, and Europe.
Q: What certifications do you have?
A: Fully in accordance with the GMP & ISO standard production and our products have passed CE certification for exporting.
Q: What is your Quality Warranty?
A: One year warranty; Lifelong Maintenance and Technical Support.
