Heavy-Duty Hydraulic Panel Turnover Machine with PLC Auto-Control and Customizable Load Capacity up to 50 Tons

Heavy-Duty Hydraulic Panel Turnover Machine with PLC Auto-Control and Customizable Load Capacity up to 50 Tons
Heavy-Duty Hydraulic Panel Turnover Machine with PLC Auto-Control and Customizable Load Capacity up to 50 Tons
Heavy-Duty Hydraulic Panel Turnover Machine with PLC Auto-Control and Customizable Load Capacity up to 50 Tons Heavy-Duty Hydraulic Panel Turnover Machine with PLC Auto-Control and Customizable Load Capacity up to 50 Tons Heavy-Duty Hydraulic Panel Turnover Machine with PLC Auto-Control and Customizable Load Capacity up to 50 Tons Heavy-Duty Hydraulic Panel Turnover Machine with PLC Auto-Control and Customizable Load Capacity up to 50 Tons Heavy-Duty Hydraulic Panel Turnover Machine with PLC Auto-Control and Customizable Load Capacity up to 50 Tons

Large Image :  Heavy-Duty Hydraulic Panel Turnover Machine with PLC Auto-Control and Customizable Load Capacity up to 50 Tons

Product Details:
Place of Origin: CHINA
Brand Name: OSMANUV
Certification: ISO9001
Model Number: OSMANUV
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Price: Negotiation
Packaging Details: WOOD PACKAGING
Delivery Time: 30 work days
Payment Terms: T/T
Supply Ability: Negotiation
Contact Now

Heavy-Duty Hydraulic Panel Turnover Machine with PLC Auto-Control and Customizable Load Capacity up to 50 Tons

Description
Coatingmethod: Roller Coating Packing Volume: 2.5
Coating Speed: High Speed Package: Wooden Case , Carton Cube
Lamp: Use Taiwanese Quartz Heating Tube Lamps Type: Ultraviolet Lamps
Drying Way: Ultraviolet - Curable Voltage: 380V/50HZ
Highlight:

Customizable Load Capacity Panel Turnover Machine

,

PLC Auto-Control Hydraulic Panel Flipper

,

Heavy-Duty Hydraulic Sheet Inverter

Heavy-Duty Hydraulic Panel Turnover Machine for Wood & Metal Sheets – Customizable Load Capacity up to 50 Tons & PLC Auto-Control
This customizable panel turnover machine is designed for automatically flipping flat panels, boards, sheets, or workpieces by 180° during production processes. Available in hydraulic heavy-duty, inline production, and precision electronic configurations.
The system is fully customizable in panel size, load capacity, cycle speed, and clamping method. By automating the flipping process, the machine reduces manual labor, prevents surface scratches, and improves production efficiency. It is widely used as auxiliary equipment in woodworking, metal processing, electronics manufacturing, and casting industries.
Working principle: The panel is conveyed into the turnover mechanism, where clamping arms or a turnover table securely holds the workpiece. The drive system (hydraulic cylinder or motor-gear mechanism) rotates the clamped panel through 180° in a controlled, smooth motion. PLC control ensures accurate positioning and repeatable cycles. The machine supports both automatic (inline) and manual operation modes.
Technical Specifications
Parameter Heavy-Duty Hydraulic Model Inline Production Model Precision Electronic Model
Max load capacity (customizable) 3 - 50 tons 100 - 1000 kg 1 - 50 kg
Max panel size (customizable) Up to 1250×2600 mm Up to 610×610 mm Up to 610×610 mm
Min panel size 250×250 mm 250×250 mm Customizable
Panel thickness range (customizable) 0.5 - 20 mm 0.05 - 20 mm 0.05 - 3.2 mm
Rotation angle 180° (0-180° customizable) 180° 180°
Cycle speed (customizable) 8 - 12 pcs/min 8 - 12 pcs/min Customizable
Conveyor speed (customizable) 0 - 20 m/min 0 - 20 m/min 0 - 20 m/min
Drive method (customizable) Hydraulic cylinder Hydraulic / Gear mechanism Motor + gear
Control system PLC + HMI touchscreen PLC + HMI touchscreen PLC + HMI
Power supply (customizable) 380V, 50/60Hz, 3-phase 220V/380V, 50/60Hz 220V, 50/60Hz
Power consumption 3 - 5 kW 0.3 - 3 kW 0.3 - 1 kW
Working height (customizable) 900±50 mm 900±50 mm Customizable
Typical application Heavy panels, metal sheets Wood panels, boards, plywood Circuit boards, thin sheets
Applications
  • Woodworking industry: Flipping plywood, particleboard, MDF during production for double-sided processing
  • Metal processing: Turning steel/aluminum sheets for cutting, welding, and surface treatment
  • Electronics manufacturing: Flipping circuit boards for component mounting and inspection
  • Casting & molding: Inverting sand molds and castings in foundry lines
  • Packaging & logistics: Turning packaged goods for labeling and stacking
  • Automotive parts: Flipping large components for assembly and inspection
Customization Options
This turnover machine is highly customizable to meet your specific production requirements:
  • Panel size & load capacity: From small circuit boards (250×250mm) to large panels (1250×2600mm+) - fully customizable
  • Load capacity: From 1kg up to 50 tons - customizable based on workpiece weight
  • Panel thickness: 0.05mm to 20mm+ - customizable
  • Drive method: Hydraulic cylinder (heavy-duty), gear mechanism, or pneumatic - customizable
  • Clamping method: Side clamping, top clamping, or vacuum suction - customizable
  • Working height: Standard 900±50mm; customizable to match your line height
  • Control system: Manual, semi-automatic, or fully automatic with PLC - customizable
  • Cycle speed: 8-12 pcs/min standard; customizable for higher throughput
  • Conveyor type: Belt, roller, or chain conveyor - customizable
  • Voltage: 220V/380V/415V - customizable to local standards
  • Non-marking rollers: Optional rubber/urethane coating to prevent surface damage - customizable
Key Features
  • Automated flipping: Eliminates manual handling - reduces labor intensity and increases safety
  • Surface protection: Smooth, controlled motion prevents scratches and damage to panels
  • PLC control: Reliable, programmable logic control with manual and automatic modes
  • High cycle speed: Up to 12 pieces per minute for high-throughput production lines
  • Robust construction: Heavy-duty steel frame and high-strength components for 24/7 operation
  • Compact footprint: Space-saving design - fits into existing production layouts
  • Safety features: Emergency stop, overload protection, interlocked safety guards
  • Precise positioning: Sensors and limit switches ensure accurate 180° rotation
  • Low noise & energy consumption: Smooth operation with optimized drive systems
  • Easy integration: Can be connected with upstream/downstream equipment in automated lines
Support and Services
  • Free process consultation - send your panel specifications for configuration advice
  • Custom layout design for your production floor
  • On-site installation and commissioning (customizable support packages)
  • Operator training program included
  • Remote troubleshooting via video call or IoT monitoring
  • 12-month warranty on mechanical components (consumables excluded)
  • Spare parts availability from regional warehouses
  • Lifetime technical support via phone, email, or chat
Packing and Shipping
  • Packing: Anti-rust film + reinforced wooden crate (with foam padding for sensitive components - control panel, sensors)
  • Standard model lead time: 10-15 days after order confirmation
  • Custom configuration lead time: 15-30 days (longer for custom sizes or heavy-duty configurations)
  • Shipping: FOB Shanghai / CIF by sea, air, or rail
  • Customizable: Export crating, custom labeling, destination port documentation
Frequently Asked Questions
What is a panel turnover machine used for?
A panel turnover machine (翻板机) is used to automatically flip flat panels, boards, or workpieces by 180° during production. It prevents surface scratches, reduces manual labor, improves safety, and increases production efficiency. It is commonly used in woodworking, metal processing, electronics, and casting industries.
What panel sizes and weights can this machine handle?
Panel size and load capacity are customizable to your needs. Standard models handle panels from 250×250mm up to 1250×2600mm, with thickness from 0.05mm to 20mm. Load capacity ranges from 1kg to 50 tons depending on configuration.
What is the typical cycle speed?
Standard cycle speed is 8-12 pieces per minute for inline production models. Higher speeds are customizable based on your production requirements.
