Quality High Precision UV Coating Metal Coil Roll Coating Line with Customizable Width for Industrial Applications factory

High Precision UV Coating Metal Coil Roll Coating Line with Customizable Width for Industrial Applications

Name: High Precision UV Coating Metal Coil Roll Coating Line with Customizable Width for Industrial Applications
Brand: Dongguan Osmanuv Machinery Equipment Co., Ltd
SKU: Specification
Price: 4,500.00 USD
Availability: InStock

High-precision industrial metal coil coating line for architectural panels & roofing. Features ±1.5μm coating tolerance, 0-80m/min speed, UV coating, and customizable roll/oven configurations. Includes closed-loop control & energy-saving hybrid oven.

Place of Origin:CHINA

Brand Name:OSMANUV

Certification:ISO9001

Model Number:Specification

Minimum Order Quantity:1 set

Price:Negotiation

Product Custom Attributes

Highlight

UV coating machine for metal coils

customizable width UV coating line

industrial UV coil coating equipment

Coatingtype:

UV Coating

Roller Material:

EPDM

Color:

Computer White + Grass Green

Coveyor Power:

0.75kw

Coatingwidth:

300-1300 Mm

Coating Qty:

10~16g/sqm

Rewinding Diameter:

400mm

Coating Width:

900 Mm

Product Description

Industrial Metal Coil Roll Coating Line | High Precision Continuous Coating System

Product Overview

This industrial roll coating line is engineered for continuous, high-speed coating of metal coils including aluminum, steel, and galvanized sheet. The system ensures uniform film thickness, excellent adhesion, and high gloss retention, making it ideal for building facades, roofing applications, and home appliance manufacturing.

Technical Specifications

Parameter	Value
Coil Width	600 - 1600 mm (customizable)
Line Speed	0 - 80 m/min
Coating Viscosity	50 - 300 cps
Drying Temperature	150 - 260°C
Coating Tolerance	±1.5 μm

Applications

Architectural panels, roofing sheets, aluminum composite panels, pre-painted galvanized steel.

Customization Options

Customizable roll diameter, coating head configuration (2-roll / 3-roll), oven zone length, and PLC control interface.

Key Features

Closed-loop coating thickness control
Automatic edge masking system
Energy-saving gas/electric hybrid oven

Support & Services

On-site installation guidance, operator training, remote troubleshooting, and spare parts supply for 10+ years.

Packing & Shipping

Shipped in steel-framed wooden cases with anti-rust film. FOB or CIF available.

Frequently Asked Questions

Q: Can I coat both sides simultaneously?

A: Yes, with customizable double-sided coating module.
