High-Efficiency Infrared Drying Line for Furniture Board & Molded Pulp Products - Energy-Saving Thermal Solution
Product Details:
| Place of Origin: | China |
| Brand Name: | Osmanuv |
| Certification: | ISO9001 |
| Model Number: | OSM-UV-1320T |
| Document: | 5 Meters IR Drying Machine.pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Wooden box |
| Delivery Time: | 45 days |
| Payment Terms: | T/T |
| Supply Ability: | Negotiation |
|
Detail Information |
|||
| Conveyor Belt Speed: | 10-30m/min | Light Source: | UV Light |
|---|---|---|---|
| Worktable: | Floating | Inverter Brand: | Schneider |
| Spray Gun: | Adopt American GRACO Automatic Spray Gun | Coating Durability: | High Durability |
| Coating Means: | DOD Inkjet Heads | Roller Type: | Steel Wire |
Product Description
High-Efficiency Infrared Drying Line for Furniture Board & Molded Pulp Products - Energy-Saving Thermal Solution
Keywords: infrared drying line, furniture board drying, molded pulp dryer, customizable drying system, industrial infrared oven
Composition of Production Line:
Pre-drying infrared module, main infrared drying tunnel, heat circulation system, temperature control cabinet, conveyor belt system, cooling section, PLC control panel
Product Description:
This infrared drying line is specifically designed for rapid and uniform drying of furniture boards (MDF, particleboard) and molded pulp products. It ensures moisture removal with minimal energy consumption and reduced footprint compared to conventional drying methods.
Technical Parameters:
| Parameter | Specification |
|---|---|
| Heating Technology | Medium-wave infrared emitters |
| Temperature Range | 50-400°C (customizable) |
| Belt Width | 600-2000mm (customizable) |
| Drying Speed | 0.5-5 m/min (adjustable) |
| Power Supply | 380V/50Hz/3Phase (configurable) |
| Control System | Siemens PLC + 10" HMI touchscreen |
| Heating Power | 30-200kW (customizable based on capacity) |
Application:
Drying of furniture boards, molded pulp packaging, egg trays, and industrial fiber products.
Customization:
Fully customizable infrared emitter layout, belt width, heating zones, and temperature profiles to match specific product requirements.
Feature:
-
40% energy saving compared to hot air drying
-
Uniform heating without surface overheating
-
Quick response and precise temperature control
-
Minimal maintenance requirements
Support and Services:
Installation supervision, operator training, 24/7 technical support, spare parts supply
Packing and Shipping:
Modular design for easy shipping, weather-proof packaging, FOB/CIF terms available
FAQ:
Q: Can the line handle different product thicknesses?
A: Yes, the temperature and speed are fully customizable for various thicknesses.
