Heating Spot Uv Coater / Automatic Coating Machine ISO9001 W920mm

Heating Spot Uv Coater / Automatic Coating Machine ISO9001 W920mm

Product Details:

Place of Origin: China
Brand Name: Osmanuv
Certification: ISO9001
Model Number: OSM-IR-UV-920T

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Wooden box
Delivery Time: 30 work days
Payment Terms: T/T, Western Union
Get Best Price Contact Now

Detail Information

Product Name: Infrared IR Tube+ UV Coating Line Color: Computer White + Grass Green
Size: 10000mm Length×1250mm Width×1400mm Height (according To Actual Size) Material: The Outer Shell Of The Heating Zone Is Made Of A3 Board, With Insulation Cotton In The Middle.
Effective Leveling Width: 920mm Lamp: Adopts Taiwanese Quartz Heating Tube With Good Heating Effect.
High Light:

ISO9001 spot uv coater


W920mm spot uv coater


ISO9001 Automatic Coating Machine

Product Description

ISO9001 W920mm Heating Stainless Steel String Rod Spot Uv Coater




 1 Conveyor belt: Adopt chain stainless steel string rod type.
 2 Transmission system: The transmission motor adopts Taiwan TWT gear reducer.
 3 Control system: Adopt Taiwan Delta frequency converter, the speed can be adjusted 5-20 meters per minute, and there is a speed digital display.
 4 Control system: BKC thermostat is used to control the temperature required for work, temperature: normal temperature -100℃ adjustable.
 5 Electrical part:

BKC thermostat, CHNT contactor, Taiwan Delta inverter, switch adopts Japanese Izumi switch, etc. All imported electrical appliances that meet international standards.


Safety system:

Over-temperature preventer, motor overload protection, control circuit insurance, emergency stop switch, etc... All electrical appliances conform to the first-class products of international standards.



Heating Spot Uv Coater / Automatic Coating Machine ISO9001 W920mm 0Heating Spot Uv Coater / Automatic Coating Machine ISO9001 W920mm 1



Q: Are you trading company or manufacturer?
A: We are a manufacturer owns foreign trade independent import and export rights. Our factory is located in Guangdong, China.
Q: How can I know your machine has good quality?
A: Firstly, we will have your samples for a trial on our machines, and make a video for you to watch the testing, factory visit is also available. Moreover, our products are widely used in China, Southeast Asia, South America, and Europe.
Q: What certifications do you have?
A: Fully in accordance with the GMP & ISO standard production and our products have passed CE certification for exporting.
Q: What is your Quality Warranty?
A: One year warranty; Lifelong Maintenance and Technical Support.
