Spray Coating Machine Spray Paint Production Line Automatic Loading And Unloading System Factory

Name: Spray Coating Machine Spray Paint Production Line Automatic Loading And Unloading System Factory
Brand: Dongguan Osmanuv Machinery Equipment Co., Ltd
SKU: OSM-SLJ-XZ620A
Price: 4,500.00 USD
Availability: InStock

Spray Coating Machine Spray Paint Production Line Automatic Loading And Unloading System 220V 50HZ 1m/min Spray Paint Production Line UV Roller Coater Scope of application Calcium silicate board, glass magnesium board, cement fiber plate, and other plates in assembly line production for smooth ...

Place of Origin:CHINA

Brand Name:Osmanuv

Certification:ISO9001 And CE

Model Number:OSM-SLJ-XZ620A

Minimum Order Quantity:1 Set

Price:Negotiable

Product Custom Attributes

Highlight

220V spray paint production line

1m/Min Automatic Loading And Unloading System

220V Automatic Loading And Unloading System

Product Name:

Automatic Loading And Unloading Machine

Size:

3800mm Long X 1300mm Wide X 3100mm High

Weight:

1600KG

Color:

Computer White / Green

Total Power:

4 KW

Conveying Speed:

1-10m/min

Product Description

Spray Coating Machine Spray Paint Production Line Automatic Loading And Unloading System

220V 50HZ 1m/min Spray Paint Production Line UV Roller Coater

Scope of application	Calcium silicate board, glass magnesium board, cement fiber plate, and other plates in assembly line production for smooth blanking mobile operations
Power part	Driven by Delta servo motor. Synchronous wheel and synchronous belt connected by keys. Linear guide rail automatic lubrication system
Operation speed	Adjustable according to process requirements, with speed range of 1-4 pieces/minute
Central conveyor speed	Roller line speed of 1-20m/min, adjustable according to actual use requirements
Material compatibility	Suitable for smooth loading and unloading of calcium silicate board, glass magnesium board, cement fiber board, board furniture, door board, medium fiber board, particle board and other boards in production line operations
Dimensions	3800mm long × 1300mm wide × 3100mm high (Subject to actual size)

UV Roller Coater Spray Coating Machine in operation

Frequently Asked Questions

Are you a trading company or manufacturer?

We are a manufacturer with independent import and export rights. Our factory is located in Guangdong, China.

How can I know your machine has good quality?

We provide sample testing on our machines with video documentation for your review. Factory visits are also available. Our products are widely used in China, Southeast Asia, South America, and Europe.

What certifications do you have?

Our production follows GMP & ISO standards and our products have passed CE certification for exporting.

What is your Quality Warranty?

One year warranty with lifelong maintenance and technical support.
