10KW Silicone Roller UV Coating Machine For Digital Print

Large Image : 10KW Silicone Roller UV Coating Machine For Digital Print

Product Details:

Place of Origin:	CHINA
Brand Name:	Osmanuv
Certification:	ISO9001 And CE
Model Number:	OSM-GTJ-1320I

Payment & Shipping Terms:

Minimum Order Quantity:	1 Set
Price:	Negotiable
Packaging Details:	Wooden Box
Delivery Time:	35-45 Working days
Payment Terms:	T/T,Western Union
Supply Ability:	According to customer's demand

Contact Now

10KW Silicone Roller UV Coating Machine For Digital Print

Description

Product Name:	Double Roll Coating Machine	Color:	Computer White / Green / Blue
Effecive Width:	1320mm	Coating Roll:	Silicone Rollet
Power:	10 KW	Weight:	1500KG
Highlight:	Silicone Roller UV Coating Machine , 10KW UV Coating Machine , Silicone Roller Coater Machine

10KW Silicone Roller UV Coating Machine For Digital Print

Silicone Roller UV Coating Machine Roll Coater For Digital Print

Roll coater is a precision device that utilizes multiple sets of rotating rollers to apply controlled amounts of coating to flat materials. This machine is ideal for various industrial applications and factory visits are available for evaluation.

Key Features

Versatile application for wood, plastic, and metal products
Ensures smooth surface finish with excellent fullness and no chromatic difference
Independent transducer and reactor control for electrooptic and rubber rollers
Imported PU doctor blade with superior abrasion and solvent resistance
Compatible with various paint types including PU, VU, NC with zero wastage
Precise coating control between 5-10g/m²

Technical Specifications

Specification	Value
Effective working width	1320 mm
Effective processing thickness	2-50 mm
Minimum machining length	300 mm
Transmission speed	2-15 m/min
Cots roller diameter	￠300 mm
Measuring wheel diameter	￠180 mm
Diameter of anti-grain wheel	￠100 mm
Pressure wheel diameter	￠70 mm
Cots length	1450 ±0.1 mm
Measuring wheel length	1450 ±0.1 mm
Anti-grain wheel length	1450 ±0.1 mm
Length of pressure wheel	1220 mm
Machine inner width	1650 mm
Machine length	4000 mm
Machine height	Conveyor belt is 850±30mm above the ground

Frequently Asked Questions

Are you a trading company or manufacturer?

We are a manufacturer with independent import and export rights. Our factory is located in Guangdong, China.

How can I verify your machine quality?

We provide sample testing on our machines with video documentation. Factory visits are available. Our products are widely used in China, Southeast Asia, South America, and Europe.

What certifications do you have?

Our production complies with GMP & ISO standards and our products have passed CE certification for international export.

What is your Quality Warranty?

One year warranty with lifelong maintenance and technical support.
