High Efficiency Wrinkle-Free Easy To Operate High Speed Film Laminating Machine
Product Details:
| Place of Origin: | China |
| Brand Name: | OSMANUV |
| Certification: | ISO9001 |
| Model Number: | OSM-FM-1320 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Wooden box |
| Delivery Time: | 40Days |
| Payment Terms: | T/T,Western Union |
| Supply Ability: | According customers requiry |
|
Detail Information |
|||
| Product Name: | High Efficiency Film Laminating Machine | Conveying Speed: | 0-15 M/min |
|---|---|---|---|
| Machine Length: | 500 Mm | Effective Conveying Thickness: | 3-80 Mm |
| Color: | White | Machine Size: | 3000mm×2670mm×1200mm |
| Effective Working Width: | 2440mm | ||
| Highlight: | High Efficiency Film Laminating Machine,High Speed Film Laminating Machine,Easy To Operate Film Laminating Machine |
||
Product Description
High Efficiency Wrinkle-Free Easy To Operate High Speed Film Laminating Machine
Product Overview
Laminating Machine with Automatic Film Cutting UV Coating, designed to cater to a wide range of industries and materials including glass, boards, PVC boards, and display screens. This cutting-edge machine combines laminating and UV coating capabilities, offering enhanced efficiency and superior results.
Download Product Documentation (PDF)Key Features
- Double-Station Film Release: Allows for alternate use and continuous operation without stopping the production line, significantly increasing productivity
- Automatic Film Cutting System: Integrated system ensures precise and efficient film cutting for smooth laminating and coating processes
- Adjustable Conveying Speed and Thickness: Speed range from 1 to 20 m/min with material thickness handling from 3 to 80 mm
- Sturdy Construction: Transmission wheel made of 45# seamless steel pipe, welded by CO², dynamically balanced with minimal runout (<0.03 mm)
- User-Friendly Design: Intuitive control panel and direct plug-in connection transmission for easy operation and maintenance
Technical Specifications
| Parameter | Specification |
|---|---|
| Effective Working Width | 0-1320 mm |
| Effective Conveying Thickness | 3-80 mm |
| Minimum Conveying Length | 300 mm |
| Conveying Speed | 1-20 m/min |
| Diameter of Driving Roller | Φ150 mm |
| Diameter of Auxiliary Drive Roller | Φ150 mm |
| Driving Roller Length | 1320 mm |
| Length of Auxiliary Drive Roller | 1320 mm |
| Machine Length | 500 mm |
| Machine Direction | From left to right |
| Machine Height | Conveyor belt 850±30 mm above ground |
| Machine Size | 3000 mm × 1550 mm × 1200 mm |
Applications
- Glass: Enhancing visual appeal and protection of glass panels, windows, and displays
- Boards: Providing protective layer and improved aesthetics for wooden boards, particle boards, and MDF
- PVC Boards: Coating for added durability, weather resistance, and vibrant colors
- Display Screens: Applying clear protective coating for scratch resistance and improved visibility
Frequently Asked Questions
Q: Are you a trading company or manufacturer?
A: We are a manufacturer with independent import and export rights. Our factory is located in Guangdong, China.
Q: How can I ensure the quality of your machine?
A: We offer trial runs of your samples on our machines, providing a video of the testing process. Additionally, you are welcome to visit our factory to witness our production capabilities. Our products are widely used and trusted in China, Southeast Asia, South America, and Europe.
Q: What certifications do you have?
A: Our production strictly adheres to GMP (Good Manufacturing Practice) and ISO standards. Our products have also obtained CE certification for international exports.
Q: What is your Quality Warranty?
A: We offer a one-year warranty for our machines, backed by lifelong maintenance and technical support.
For further inquiries or to explore how our advanced Laminating Machine with Automatic Film Cutting UV Coater can meet your specific requirements, please contact us. We are committed to providing innovative solutions and exceptional service to our valued customers.
